Chinese laborers machinery - three in one feeding machine operation method

Three in one combination of material feeding machine frame, leveling machine, NC feeding machine, greatly reduces the previous feeding device occupied area, and with the punch, and can be placed in the ordinary floor, and installed in the rack on the material by the photoelectric control under control, NC the feeding machine can be preset while leveling, while the feeding length of the material sent to die, and with high precision die in an instant relaxation material movement.
The operation of each auxiliary device is powered by air or electricity. The operation is simple and the maintenance is easy. After the completion of debugging, the failure rate is low, the leveling is relaxed and the feeding accuracy is high. The operation of the three in one feeding machine is extremely simple, and the specific process is as follows:
1. make sure the three in one feeder line is in line with the center line of the mold line and connect the power supply to make sure the ground is normal.

2., three in one feeder charging
2.1. Place the material on the crane and be stable.
2.2, according to the oil pressure to relax, the material frame to a certain diameter, the material slowly into the material spindle, and make the material axial center surface and the tile plate on the scale coincide, stop moving forward, remove the crane.
2.3, material placement, according to the expansion of oil pressure tight material, at this time the material is in a tight state.
2.4 、 lower the pressure hydraulic pressure arm, and put the knob in the automatic position, raise the arm, remove the material packing tape, pay attention to the material rebound. (the hydraulic pressure arm must be under pressure, otherwise it may cause material dispersion and pay attention to the position of the person.)
3., three in one feeding machine feeding
3.1, rising feed feeding arm to a certain position, the rack knob is set manually, manual control frame is transferred, the material feeding slowly into the arm, under pressure pressing arm, clamping material, click the touch screen into the material feeding switch, forcing the material to the machine head, and control rack is turn, when the material near the nose, up into the feed arm and the pressing arm, the pressing arm on the head, relax into the cylinder and the cylinder head into the material leveling. (this process controls the feeding arm and the material feeding switch). Attention should be paid to the automatic status of the press arm, or the loose material will appear.
3.2. Clamping the feeding cylinder, leveling the cylinder, loosening the feeding cylinder, making the material pass through the head, and then adjust the leveling height, clamping the feeding cylinder.
4., three in one feeder machine head parts of the adjustment
4.1 、 feeding roller pressure adjustment
By adjusting the pressure regulating valve, the upper roller and the lower roller can not slide, and simultaneously control the air pressure, so as to avoid damaging the material, producing indentation or slipping.
4.2, material offset
If the material is not to be offset, should confirm whether the mold in parallel and arranged in the center of the table immediately into the leveling machine material is in the middle and right angle, this operation can be determined by measuring to, if not slightly positive, can slow the speed by adjusting the gauge wheel location.
4.3, material leveling adjustment
Material leveling principle: leveling drum is in zigzag arrangement, if the entrance side of the flat roller down, the material along the roller bending, if the export side of the flat roller pressure too much, the material is bent downward. Generally speaking, the inlet side is lowered to the upper and lower leveling roller gap than the material thickness of 1 to 1.5mm position, while the export side is adjusted to the same as the gap between the material (ordinary materials).
5. 、 three in one feeding adjustment
When the above operations have been completed, the feeding parameters can be set up, and the specific operation method can be seen in the man-machine interface operation method, and after completion, the normal production can be entered.
