PRODUCT
Introduction:
Material width: 400-600 mm
Material thickness: 0.3-2.3 mm
Standard configuration:
1. photoelectric arc control system;
2. feeding roller and correcting roller plating hard chromium treatment;
3. feeding outlet guide rack device;
4. feeding line height electric regulating device;
5. material arc control roller;
6. material rack hydraulic expansion equipment;
7. material rack frequency conversion speed regulation;
8. press arm device;
9. material frame with empty disc brake.
Purchase configuration:
1. hydraulic automatic feeding trolley;
2. roller full drive device;
3. double face oiling device
The stress at the point of stress in the upper table is 275N/mm2 (tensile strength 400N/mm2)
The, above, figures, are, material, having, yield, strenggth, of, 275N/mm2, (Tensile, strength, of, 400N/mm2)
Specifications and appearance due to improvements may change without notice
